• Air conditioning, dual-zone, manual, individual climate settings for driver & right front passenger
• Cigarette lighter, on instrument panel
• Floor covering, rubberized vinyl, Black
• Headliner, Shale-colored cloth, w/matching retainer moldings
• Lighting, dome lamp, reading, courtesy, illuminated entry feature, backlit instrument panel switches & door handle-activated illuminated entry
• Mirror, inside rearview, manual day/night
• Sound system feature, 4-speakers
• Theft-deterrent system, PASSLock II
• Visors, padded, Shale-colored, driver & passenger side w/cloth trim, extenders, pocket on driver side & vanity mirror on passenger side
• Warning tones, headlamp on, key-in-ignition, driver safety belt unfasten, turn signal on

• Alternator, 105 amps
• Brakes, 4-wheel antilock, 4-wheel disc
• Dual rear wheels
• Exhaust, aluminized stainless-steel muffler & tailpipe
• Frame, ladder-type
• Rear axle, 4.10 ratio
• Rear wheel drive
• Suspension Package, Handling/Trailering, heavy-duty
• Suspension, front, independent torsion bar, & stabilizer bar
• Suspension, rear, semi-elliptic 2-stage multi-leaf springs
• Tools, mechanical jack & wheel wrench, gloves, courtesy mat, spare tire assist hook, floor-mounted in back of cab
• Trailering wiring harness, 7-wire

• Air bags, frontal, driver & right front passenger-inc: passenger side deactivation switch
• Brakes, 4-wheel antilock, 4-wheel disc
• Daytime running lamps-inc: automatic exterior lamp control
• Manual lap safety belts, center seat position
• Manual lap/shoulder safety belts, outboard seat positions
• Side guard door beams
• Single note horn

BATTERY, AUXILIARY HEAVY-DUTY, 600 COLD-CRANKING AMPS

• rundown protection & retained accessory pwr

PAINT, SOLID

• (STD)

SUSPENSION PACKAGE, HANDLING/TRAILERING, HEAVY DUTY

• (STD)

REAR AXLE, 4.10 RATIO

• (STD)

GVWR, 11,400 lbs. (5171 kg)

• (STD)

BODY, CHASSIS CAB

• (STD)

ALTERNATOR, 145 AMP

• 145 amp alernator in place of the standard 105 amp alternator

BACKUP ALARM

• 97 decibels back-up alarm

TIRES, LT215/85R16D, ON-/OFF-ROAD, BLACKWALL

• 6 tires

SEATS, FRONT VINYL 40/20/40 SPLIT-BENCH, 3-PASSENGER, DRIVER & PASSENGER MANUAL RECLINING

• w/outboard head restraints
• available in front cloth (STD)

TRANSMISSION, 4-SPEED AUTOMATIC, HEAVY-DUTY, ELECTRONICALLY CONTROLLED W/OVERDRIVE

• tow/haul mode & (KNP) Cooling
• external transmission oil cooler

MARKETING OPTION PKG

• Base Decor

ENGINE, VORTEC 6000 V8 SFI (300 HP [223.8 kW] @ 4400 rpm, 360 lb.-ft. [486.6 N-m] @ 4000 rpm)

• (STD)

• BATTERY AUXILIARY HEAVY-DUTY 600 COLD-CRANKING AMPS -inc: rundown protection & retained accessory pwr
• PAINT SOLID (STD)
• CLOTH SEAT TRIM
• TIRE SPARE LT215/85R16D ON-/OFF-ROAD BLACKWALL
• SUSPENSION PACKAGE HANDLING/TRAILERING HEAVY DUTY (STD)
• REAR AXLE 4.10 RATIO (STD)
• MIRRORS OUTSIDE REARVIEW RIGHT-HAND & LEFT-HAND WEST COAST-TYPE BLACK (7" wide x 16" high)
• GVWR 11 400 lbs. (5171 kg) (STD)
• BODY CHASSIS CAB (STD)
• ALTERNATOR 145 AMP 145 amp alernator in place of the standard 105 amp alternator
• BACKUP ALARM 97 decibels back-up alarm
• RECOVERY HOOKS 2 FRONT FRAME-MOUNTED
• TIRES LT215/85R16D ON-/OFF-ROAD BLACKWALL -inc: 6 tires
• SEATS FRONT VINYL 40/20/40 SPLIT-BENCH 3-PASSENGER DRIVER & PASSENGER MANUAL RECLINING w/outboard head restraints available in front cloth (STD)
• TRANSMISSION 4-SPEED AUTOMATIC HEAVY-DUTY ELECTRONICALLY CONTROLLED W/OVERDRIVE -inc: tow/haul mode & (KNP) Cooling external transmission oil cooler
• MARKETING OPTION PKG -inc: Base Decor
• ENGINE VORTEC 6000 V8 SFI (300 HP [223.8 kW] @ 4400 rpm 360 lb.-ft. [486.6 N-m] @ 4000 rpm) (STD)
• Rear Wheel Drive
• Dual Rear Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Dual Rear Wheels
• Steel Wheels
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Daytime Running Lights
• Intermittent Wipers
• Split Bench Seat
• Adjustable Steering Wheel
• Immobilizer
• Climate Control
• Multi-Zone A/C
• A/C
• AM/FM Stereo
• Power Outlet
• Front Reading Lamps
• ABS
• 4-Wheel Disc Brakes
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag On/Off Switch
• Daytime Running Lights

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Cold Cranking Amps @ 0° F (2nd): 600
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): 15.4
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4500
• Gross Axle Wt Rating - Rear (lbs): 8550
• Curb Weight - Front (lbs): 2917
• Curb Weight - Rear (lbs): 2314
• Gross Vehicle Weight Rating Cap (lbs): 11,400
• Gross Combined Wt Rating (lbs): 16000
• Suspension
• Suspension Type - Front: Indep Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 4500
• Spring Capacity - Rear (lbs): 8600
• Axle Type - Front: Independent
• Axle Type - Rear: Full Floating
• Axle Capacity - Front (lbs): 4800
• Axle Capacity - Rear (lbs): 9200
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.25
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.8 x 1.5
• Rear Brake Rotor Diam x Thickness (in): 12.8 x 1.2
• Tires
• Front Tire Order Code: XYL
• Front Tire Order Code: XYK
• Rear Tire Order Code: XYL
• Rear Tire Order Code: XYK
• Spare Tire Order Code: ZYL
• Front Tire Size: LT215/85R16D
• Rear Tire Size: LT215/85R16D
• Spare Tire Size: LT215/85R16D
• Front Tire Capacity (lbs): 2335
• Rear Tire Capacity (lbs): 2150
• Spare Tire Capacity (lbs): 2150
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Turning Diameter - Curb to Curb (ft): 44.9
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 27
• Aux Fuel Tank Capacity, Approx (gal): 23
• Fuel Tank Location: Inboard LH Frame
• Aux Fuel Tank Location: Rear
• Exterior Dimensions
• Wheelbase (in): 137.0
• Length, Overall w/o rear bumper (in): 225.0
• Width, Max w/o mirrors (in): 86.0
• Height, Overall (in): 76.0
• Overhang, Front (in): 37.0
• Overhang, Rear w/o bumper (in): 51.0
• Front Bumper to Back of Cab (in): 113.6
• Cab to Axle (in): 60.4
• Cab to End of Frame (in): 111.4
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 41.1
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.7
• Front Hip Room (in): 61.5
• Summary
• Vehicle Name: Chevrolet Silverado 3500
• Body Style: Reg Cab 137.0" Wheelbase
• Body Code: ZW9
